Asset-Eyes develops precision tooling solutions to achieve critical surface finish requirements across metals, composites, and engineered plastics, using rigorous GD&T analysis to ensure consistent, repeatable manufacturing from the first run. With SolidWorks and AutoCAD, we design complete tooling assemblies such as custom insert cutter configurations, precision reamer setups and specialized finishing tools aligned with ASME Y14.5 and ASME B46.1 standards to control geometry and surface texture (Ra, Rz). Our deliverables include detailed 3D models, manufacturing drawings with cutting parameters, and process documentation that links tooling features to GD&T requirements, enabling machinists to meet target finishes efficiently without trial-and-error or rework.
